Titanium Grade 23 Fasteners

Titanium Grade 23 Fasteners (6 AL-4V ELI) Supplier

Titanium Fastener /

Titanium Grade 23 Fasteners (6 AL-4V ELI) Supplier Titanium Grade 23 Fasteners (6Al-4V ELI) is a premium titanium alloy designed for the most demanding industries—medical implants, aerospace hardware, high-performance racing, and offshore applications.   Titanium Grade 23 (UNS R56401) is a high-purity variant of the more common Titanium Grade 5 (Ti-6Al-4V). It contains the same main alloying elements: 6% Aluminum 4% Vanadium but with much lower levels of interstitial impurities like oxygen, nitrogen, carbon, and iron.   This subtle refinement significantly improves ductility and fracture toughness while maintaining impressive strength. But what makes these fasteners so special? Let’s explore why Titanium Grade 23 fasteners are prized for their remarkable combination of strength, corrosion resistance, and biocompatibility.   This grade of titanium was specifically engineered to address the subtle yet crucial demands of life-critical applications: It needs to be strong enough to support mechanical loads. Light enough to reduce mass and improve efficiency. Pure enough to exist in harmony with living tissue. And tough enough to absorb shocks without cracking under pressure. In essence, Titanium Grade 23 fasteners are built not for ordinary use, but for the extraordinary.   They are chosen not because they’re the cheapest—but because they offer what no other material can: a rare balance of biocompatibility, corrosion resistance, structural reliability, and long-term performance. Whether it’s the skeletal frame of a satellite or the skeletal frame of a human being, these fasteners become the invisible threads holding innovation—and in some cases, life itself—together.   So the next time you see a state-of-the-art medical device, a sleek fighter jet, or a deep-sea exploration vessel, remember: behind the cutting-edge design is a set of components quietly doing their job without fail. Titanium Grade 23 fasteners don’t ask for attention. They simply deliver quiet confidence in the face of impossible conditions. Table of Contents Titanium Grade 23 Fasteners (6 AL-4V ELI)  Specification Standard ASTM B348 / ASME SB348 Bolt / Screw Size M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size M1.6 – M12 Self Tapping Screw Size No.2 – No. 14 Length 3 mm to 200 mm Threads UNF, BSW, BSF, METRIC, UNC, or as required Fasteners DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts Form Hex, Threading, Square, Round as per Gauge Etc. Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads Certification Dual Certified As per ASTM & ASME Codes Dimensions DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 Threads Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically Test Certificate as per EN 10204 / 3.1 Manufacturer Test Certificate Additional Certifications PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified Production Process M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC Types Bolts, Nuts, Stud Bolts, Washers, Threaded Rod, Anchor Fasteners, Eye Bolt, Stud, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, Hexagon Castle Nuts, Hexagon Domed Cap Bolts, Hexagon Thin Nuts etc.   Titanium Grade 23 Fasteners ( 6AL 4V ELI ) Equivalent Material ANDARD UNS WERKSTOFF NR. Titanium Gr 23 R56401 3.7165   Titanium Grade 23 Fasteners (6 AL-4V ELI)  Price List Price List of Titanium 6 AL-4V ELI Fasteners Titanium Alloy Grade 23 Fasteners Price in India (INR) Ti-6al-4v Fasteners Price in USD Titanium Alloy Gr 23 Fasteners Price in UAE (Dirham) Titanium Alloy 6AL 4V ELI Fasteners Price List ₹ 5,823 $ 32.43 USD 152.17 AED Grade 23 Ti Alloy Bolts and Nuts Price List ₹ 1,734 $ 37.35 USD 50.73 AED Ti Alloy 6 AL-4V ELI Nut Bolt Price Per Kg ₹ 8,395 $ 36.00 USD 56.10 AED Gr 23 Titanium Alloy Screws Price ₹ 3,075 $ 66.54 USD 44.25 AED Alloy 6AL 4V ELI Hex Bolt Price List ₹ 3,290 $ 8676.32 USD 360.50 AED Gr 23 Titanium Bolts Price List ₹ 4,600 $ 24.75 USD 55.87 AED Price of Titanium 6 AL-4V ELI Stud Bolt ₹ 8,403 $ 35.70 USD 164.71 AED M8 Titanium Grade 23 Hex Flange Nut Price ₹ 4,500 $ 33.19 USD 53.76 AED M16 5/8inch Ti-6al-4v Hex Head Bolt Price List ₹ 6,450 $ 45.31 USD 125.27 AED     Titanium Grade 23 Fasteners (6 AL-4V ELI) Hardness, Impact Test, Hydrostatic Test. Manufacturing Facilities.  Hot Dipped Galvanizing  PTFE Coated  Zinc Phosphate  Zinc Electro Plating  ZAC (Zinc Aluminum Flake Coating)   Titanium Grade 23 Fasteners (6 AL-4V ELI) Chemical Composition Ti 88.09 – 91% Al 5.5 – 6.5%%  V 3.5 – 4.5%  Fe <=0.25%  C <=0.080% N <=0.030%  H <=0.0125%  Other, each <=0.10%  Other, total <=0.40%   Titanium Grade 23 Fasteners (6 AL-4V ELI) Mechanical Properties Property Minimum Maximum Yield Strength Range (Rp0.2 Offset) (ksi) 120 160 Tensile Strength Range (Rm) (ksi) 125 174 Elongation (AL=5 x Ø) 10.0% 18.0% Brinell Hardness (H) 326 379 Modulus of Elasticity (ksi) (E): 16500               Machineability General Index: 21%               Titanium Grade 23 Fasteners (6 AL-4V ELI) Applications  Medical Implants – Bone screws, plates, and surgical instruments requiring biocompatibility. Aerospace – Airframe assembly, engine mounts, and interior components needing lightweight strength. Motorsport – High-performance race cars and motorcycles for weight savings and reliability. Marine & Offshore – Corrosion-resistant fixtures in seawater environments. Chemical Processing – Fasteners exposed to aggressive chemicals and high temperatures. Ready to Ship, Wherever You Need Reliable Supplies for your next big project?    Whether you’re based in India or shipping internationally, we’re here to make sourcing simple. We supply across the USA, Canada, Australia, Germany, Brazil

Titanium Grade 23 Fasteners (6 AL-4V ELI) Supplier Read More »

Titanium Grade 7 Fasteners

Titanium Grade 7 Fasteners Manufacturer, Supplier

Titanium Fastener /

Titanium Grade 7 Fasteners Manufacturer, Supplier Titanium Grade 7 Fasteners is not just another titanium alloy—it’s a high-performance material alloyed with palladium, offering outstanding resistance to corrosion, especially in acidic and chloride-rich environments. Whether you’re working in chemical processing, power generation, offshore drilling, or marine construction, you need a bolt that won’t rust, seize, or break under pressure. Titanium Grade 7 bolts are designed specifically for such environments, offering exceptional chemical resistance, high strength-to-weight ratio, and temperature stability up to 800°C.   Unlike stainless steel or standard alloy bolts, Titanium Grade 7 bolts provide a unique combination of lightweight construction and long-term durability, making them a preferred choice for high-specification projects. Their non-magnetic and biocompatible nature also opens doors to sensitive applications such as medical devices and instrumentation.   What truly sets these bolts apart is their versatility. Available in various configurations—hex bolts, U-bolts, studs, machine screws, eye bolts, and custom forms—Titanium Grade 7 fasteners are suitable for both structural and functional purposes. And thanks to the ASTM B348 standard (UNS R52400), manufacturers and engineers can trust their consistency and quality across international markets.   In this detailed guide, we’ll explore everything you need to know about Titanium Grade 7 bolts—their composition, types, benefits, and applications—along with related high-performance alloys like Super Duplex UNS S32750. Whether you’re a procurement officer, design engineer, or industrial contractor, this blog will help you understand why Titanium Grade 7 is a material that delivers far more than it weighs. Table of Contents Here are the details for Titanium Grade 7 fasteners:   Titanium Grade 7 fasteners Chemical Composition – Iron (Fe): 0.3% max – Oxygen (O): 0.25% max – Palladium (Pd): 0.12-0.25% – Carbon (C): 0.08% max – Nitrogen (N): 0.03% max – Hydrogen (H): 0.015% max – Other elements: 0.4% max – Titanium (Ti): Remainder   Titanium Grade 7 fasteners Mechanical Properties – Yield Strength: 50.763 ksi (350 MPa) max – Tensile Strength: 70.343 ksi (485 MPa) max – Elongation: 28% max – Hardness: 150 HV max – Modulus of Elasticity: 14938 ksi (103 GPa)   Titanium Grade 7 fasteners Physical Properties – Density: approximately 4.5 g/cm³ (similar to other titanium alloys)   Titanium Grade 7 fasteners Applications – Chemical processing equipment – Desalination plants – Marine environments with high chloride exposure – Anode, cathode, and cell components – Pulp and paper bleaching, washing equipment – Hydrometallurgical extraction and electrowinning   Titanium Grade 7 Fastener Styles – Titanium screws (12 point, button head, flat head, hex head, pan head, socket head) – Titanium bolts (hex head, shoulder bolts) – Titanium nuts (hex nuts, lock nuts, jam nuts) – Titanium washers (flat washers, lock washers)   Titanium Grade 7 fasteners Specifications – ASTM: B265, B337, B338, B348, B363, B381, B861, B862 – AMS: various specifications – DIN/ISO: various specifications (e.g., DIN 6923, ISO 19513)   Unfortunately, I couldn’t find information on weight per meter or thickness charts specific to Titanium Grade 7 fasteners. For pricing, it’s best to contact suppliers directly, as prices can vary depending on the specific product, quantity, and supplier ¹ ².   Standard ASTM B348 / ASME SB348 Bolt / Screw Size M3 – M56 | 3/6″ to 2″ | Custom Sizes Nuts Size M3 – M56 | 3/6″ to 2″ | Custom Sizes Washers Size M3 – M56 | 3/6″ to 2″ | Custom Sizes Machine Screws Size M1.6 – M12 Self Tapping Screw Size No.2 – No. 14 Length 3 mm to 200 mm Threads UNF, BSW, BSF, METRIC, UNC, or as required Fasteners DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Stud Bolt length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Hex nuts Form Hex, Threading, Square, Round as per Gauge Etc. Threads Configuration ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads Certification Dual Certified As per ASTM & ASME Codes Dimensions DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 Threads Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically Test Certificate as per EN 10204 / 3.1 Manufacturer Test Certificate Additional Certifications PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified Production Process M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC Types Bolts, Nuts, Stud Bolts, Washers, Threaded Rod, Anchor Fasteners, Eye Bolt, Stud, Cotter Pin, Socket Screw, Fine Fasteners & Spares, Foundation Fasteners, Hexagon Castle Nuts, Hexagon Domed Cap Bolts, Hexagon Thin Nuts etc.   Ready to Ship, Wherever You Need Reliable Supplies for your next big project?  Whether you’re based in India or shipping internationally, we’re here to make sourcing simple. We supply across the USA, Canada, Australia, Germany, Brazil , and the United Kingdom. Fast quotes, custom sizes, and bulk orders available. Let us know what you need—we’ll take care of the rest.   Here are the details for Titanium Grade 7 fasteners:   Titanium Grade 7 fasteners Chemical Composition – Iron (Fe): 0.3% max – Oxygen (O): 0.25% max – Palladium (Pd): 0.12-0.25% – Carbon (C): 0.08% max – Nitrogen (N): 0.03% max – Hydrogen (H): 0.015% max – Other elements: 0.4% max – Titanium (Ti): Remainder   Titanium Grade 7 fasteners Mechanical Properties – Yield Strength: 50.763 ksi (350 MPa) max – Tensile Strength: 70.343 ksi (485 MPa) max – Elongation: 28% max – Hardness: 150 HV max – Modulus of Elasticity: 14938 ksi (103 GPa)   Titanium Grade 7 fasteners Physical Properties – Density: approximately 4.5 g/cm³ (similar to other titanium alloys)   Titanium Grade 7 fasteners Applications – Chemical processing equipment – Desalination plants – Marine environments with high chloride exposure – Anode, cathode, and cell components – Pulp and paper bleaching, washing equipment – Hydrometallurgical extraction and electrowinning   Titanium Grade 7 Fastener Styles – Titanium screws (12 point, button head, flat

Titanium Grade 7 Fasteners Manufacturer, Supplier Read More »

Monel 400 Buttweld Fittings

Monel 400 Buttweld Fittings

Nickel Alloy Buttweld Fittings /

Monel 400 Buttweld Fittings Monel 400 buttweld fittings take all of the alloy’s natural advantages and turn them into precisely engineered components designed to create durable, strong, and long-lasting piping systems. These fittings aren’t just metal—they’re peace of mind for engineers who can’t afford to compromise on safety, reliability, or service life.   But why exactly is Monel 400 so popular? How do its buttweld fittings compare to other types of fittings? What industries depend on them? And what specifications should buyers look for?   In this in-depth guide, we’ll break down everything you need to know about Monel 400 buttweld fittings—from their chemical composition and mechanical properties to their real-world applications and advantages. Whether you’re a procurement manager sourcing    materials for a new project, an engineer designing a critical pipeline, or simply someone trying to better understand industrial materials, you’ll find this guide a practical, clear, and valuable resource.   Let’s dive in and explore why Monel 400 buttweld fittings have become a staple in some of the world’s most demanding industries.   Monel 400 buttweld fittings are pipe fittings manufactured from the Monel 400 alloy (UNS N04400), designed to connect sections of pipe in a secure, leak-proof way through welding. Unlike threaded or socket-weld fittings, buttweld fittings provide smooth inner surfaces and gradual transitions, minimizing pressure drop and turbulence. These fittings are critical in process piping systems where high strength, durability, and corrosion resistance are required—even in harsh environments such as seawater or acidic conditions. Table of Contents Monel 400 ButtWeld Fittings Stock Size Range and Specifications Grade Monel 400 / UNS N04400   Standard ASTM B366, ASME SB366   Dimensions ASME B16.28, ASME/ANSI B16.9, MSS-SP-43   Monel 400 Seamless Fittings 1/2″ NB – 10″ NB   Monel 400 Welded Fittings 1/2″ NB – 48″ NB   Form 90 Elbow, 45 Elbow, Long Radius Elbow‘ Short Radius Elbow, Concentric Reducer, Eccentric Reducer, Equal Tee, Unequal Tee, Lateral Tee, Cross, Bends 1.5d, 3d, 5d, 10d, U bend, 180 Deg Bend, Short Stub End, Long stub end, Concentric Reducer,End Cap, Dish Cap, Lap-joint   Schedule SCH 5 To SCH XXS   Wall Thickness from 2 to 40 mm   Type Seamless / Welded / Fabricated   Monel 400 butt-weld fittings Chemical Composition – Nickel (Ni): 63% min – Copper (Cu): 28-34% – Iron (Fe): 2.5% max – Manganese (Mn): 2% max – Carbon (C): 0.3% max – Silicon (Si): 0.5% max – Sulfur (S): 0.024% max   Monel 400 ButtWeld Fittings Mechanical Properties – Tensile Strength: 550-690 MPa (80-100 ksi) – Yield Strength: 240-310 MPa (35-45 ksi) – Elongation: 35% min – Hardness: 110-150 HB   Monel 400 ButtWeld Fittings Physical Properties – Density: 8.8 g/cm³ – Melting Point: 1300-1350°C   Monel 400 ButtWeld Fittings Applications – Marine applications: Monel 400 is resistant to seawater corrosion and is often used in marine hardware. – Chemical processing: The alloy’s resistance to corrosion by acids and alkalis makes it suitable for chemical processing applications. – Aerospace: Monel 400 is used in aerospace applications due to its high strength and resistance to corrosion.   Monel 400 ButtWeld Fittings Specifications – ASME B16.9: Monel 400 butt-weld fittings meet the requirements of ASME B16.9 standard specification for factory-made wrought butt-welding fittings. – ASTM B366: The material meets the requirements of ASTM B366 standard specification for factory-made wrought nickel and nickel alloy fittings.   Other Forms / Products Available Monel 400 Pipe Fitting Monel 400 Butt weld Fitting Monel 400 Seamless Fitting Monel 400 Welded Fitting Monel 400 90 Elbow Monel 400 45 Elbow UNS N04400 Long Radius Elbow WNR. 2.4360 Short Radius Elbow Monel 400 Concentric Reducer Monel 400 Eccentric Reducer Monel 400 Equal Tee Monel 400 Unequal Tee Monel 400 Lateral Tee UNS N04400 Fitting Cross Monel 400 Pipe Bends Monel 400 U Bend Monel 400 180 Deg bend Monel 400 Short Stub end UNS N04400 Stub End Monel 400 End Cap Monel 400 Dish Cap Monel 400 Buttweld Fittings Price List UNS N04400 Long Radius Elbow : US $0.5-1000 / Piece (FOB Price). Monel 400 Eccentric Reducer : US $300-500 / Ton (FOB Price). WNR. 2.4360 Short Radius Elbow : US $1-900 / Piece (FOB Price). UNS N04400 Fitting Cross : US $0.5-1000 / Piece (FOB Price). Monel 400 Pipe Bends : US $1-300 / Piece (FOB Price). Ready to Ship, Wherever You Need Reliable Supplies for your next big project?  Whether you’re based in India or shipping internationally, we’re here to make sourcing simple. We supply across the USA, Canada, Australia, Germany, Brazil , and the United Kingdom. Fast quotes, custom sizes, and bulk orders available. Let us know what you need—we’ll take care of the rest. Supplies from Different Countries Supplies from Different Countries Flag Country Code 🇮🇳 India IN 🇺🇸 United States US 🇬🇧 United Kingdom GB 🇨🇳 China CN 🇯🇵 Japan JP 🇩🇪 Germany DE 🇮🇹 Italy IT 🇹🇷 Turkey TR 🇦🇪 United Arab Emirates AE 🇸🇦 Saudi Arabia SA 🇶🇦 Qatar QA 🇴🇲 Oman OM 🇰🇼 Kuwait KW 🇦🇺 Australia AU 🇨🇦 Canada CA 🇳🇱 Netherlands NL 🇮🇩 Indonesia ID 🇪🇬 Egypt EG

Monel 400 Buttweld Fittings Read More »

Hastelloy C276 Fittings

Hastelloy C276 Buttweld Fittings

Nickel Alloy Buttweld Fittings /

Hastelloy C276 Buttweld Fittings Hastelloy C276 Buttweld Fittings are widely used in demanding environments where both high temperatures and aggressive corrosion are concerns. This alloy is known for its excellent resistance thanks to its unique composition— a nickel-molybdenum-chromium superalloy stabilized with tungsten for extra durability. Designed to perform in harsh chemical processing and industrial settings, these fittings are manufactured to ASTM B366 specifications. Leading suppliers like Navstar Steel offer a complete range of Hastelloy C276 fittings in different types, sizes, and thread options, including seamless and buttweld forms.   As a manufacturer of ANSI B16.9 Hastelloy C276 Tee, ANSI B16.9 BW C276 End Cap, and other critical components, we provide quality solutions for demanding piping systems. Seamless fittings are valued for precision and smooth bore, making them ideal for instrumentation lines, while buttweld fittings are preferred for their high strength and reliable welded joints. The Alloy C276 Buttweld Pipe Elbow is often chosen over standard pipe bends because it provides a smoother directional change with controlled flow characteristics. Available in long radius and short radius forms (typically 45° and 90° angles), these elbows support nominal diameters from ½ inch up to 48 inches. Similarly, the Alloy C276 Reducer ensures smooth transitions between pipe sizes by reducing the diameter as needed. Table of Contents  Material & Standards Specification: ASTM B366 / ASME SB366 Standards: ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 Types: Seamless, Welded, Fabricated Sizes: Seamless: ½″ – 10″ Welded: ½″ – 48″ Thickness/Schedules Available: 5s, 10s, 40s, 80s, STD, XS, 160, XXS, up to 50mm in welded fittings NACE Compliance: MR 01-75 These fittings are manufactured to meet strict international standards, ensuring they perform reliably in corrosive environments where failure is not an option.   Hastelloy C276 Pipe Fittings Specification Specification ASTM B366 / B564, ASME SB 366 / SB564 Thickness Sch 20, 10, 40, 60, STD, 80, 100, XS, 120, 160, 140, Sch XXS Dimensions ANSI/ASME B16.28, B16.9, MSS-SP-43. Grades Hastelloy B2 (UNS No. N10665), Hastelloy C22 (UNS No. N06022), Hastelloy C-4 (UNS No. N06455) Size 1/2″upto 12″NB IN Types Seamless / Welded / ERW / Fabricated   ASTM B366 UNS N10276 Material Price Products Fitting Pipe Size Price HASTELLOY C-276- PIPES & PIPE FITTINGS REDUCER ECC HASTELLOY C-276 SIZE 4 X 3 X SCH40 3/4 in x 3/4 in $52.17 HASTELLOY C-276- PIPES & PIPE FITTINGS FLANGE SIZE:1INCH,150# ,A105/LJ/SB-HAST-C276 STUB END (SHORT) 1 in x 1 in $51.12 PIPE FITTING -0.750IN,CAP-BUTTWELD,HASTELLOY C- 276 PER ASTM B366 (QTY-5) 1-1/4 in x 1-1/4 in $78.84 PIPE FITTINGS COUPLING HALF COUPLING HASTELLOY C THREADED 1 INCH 3000 1-1/2 in x 1-1/2 in $105.66 EQUAL TEE 2X2X2 NB SCH 40 HASTELLOY C-276 SEAMLESS (NICKEL PIPES FITTING) 2-1/2 in x 2-1/2 in $186.55   Werkstoff Nr. 2.4819 Tee Weight Chart KG LBS NPS 0.59 1.3 2-1½ 0.54 1.2 2-1¼ 0.5 1.1 2-1 – – 2-3/4 1.11 2.45 2½-2 1 2.2 2½-1½ 0.95 2.1 2½-1¼ – – 2½-1 1.88 4.15 3-2½ 1.59 3.5 3-2 1.45 3.2 3-1½ – – 3-1¼ 2.72 6 3½-3 2.45 5.4 3½-2½ 2.04 4.5 3½-2 – – 3½-1½ – – 3½-1¼ 3.72 8.2 4-3½ 3.4 7.5 4-3 4.76 10.5 4-2½ 2.7 5.95 4-2 – – 4-1½ 5.94 13.1 5-4 5.53 12.2 5-3½ 5.17 11.4 5-3 4.76 10.5 5-2½ – – 5-2 9.39 20.7 6-5 8.35 18.4 6-4 7.85 17.3 6-3½ 7.44 16.4 6-3 – – 6-2½ 17.78 39.2 8-6 16.1 35.5 8-5 14.7 32.4 8-4 – – 8-3½ 32.3 71.2 10-8 27.76 61.2 10-6 25.72 56.7 10-5 – – 10-4 50.58 111.5 12-10 43.77 96.5 12-8 38.42 84.7 12-6   Hastelloy C22 Pipe Fittings Applications Petrochemical Industries Gas Processing Industries Fertilizers Industries Power Generation Industries Chemical Industries Oil & Gas Industries Nuclear Industry Pulp & Paper Industry UNS N10276 Reducer Chemical Composition Grade Ni C Cr Mn Mo Si Fe S P Co C276 50.99 min* 0.010 max 14.50 – 16.50 1.00 max 15.00 – 17.00 0.08 max 4.00 – 7.00 0.03 max 0.04 max 2.50 max C22 50.015 min* 0.010 max 20.00 – 22.50 0.50 max 12.50 – 14.50 0.08 max 2.00 – 6.00 0.02 max 0.02 max 2.50 max B2 Bal 0.02 max 1.0 max 1.0 max 26 – 30 0.1 max 2.0 max 0.03 max 0.04 max 1.0 max Hastelloy C Pipe Fittings Mechanical Properties Element Tensile Properties Density Yield Properties Melting Point Elongational Hastelloy C276 MPa – 790,  Psi – 1,15,000 8.089 g/cm3 MPa – 355,  Psi – 52,000 1370 °C (2500 °F) 40 % Hastelloy C22 Psi – 1,00,000 , MPa – 690 8.69 g/cm3 Psi – 45000 , MPa – 310 1399 °C (2550 °F) 45 % Hastelloy B2 Psi – 1,10,000 , MPa – 760 9.2 g/cm3 Psi – 51000 , MPa – 350 1370 °C (2500 ºF ) 40 %   2.4819 Pipe Reducing Tee Equivalent STANDARD GOST EN UNS OR WERKSTOFF NR. JIS Hastelloy C276 ХН65МВУ NiMo16Cr15W N10276 ЭП760 2.4819 NW 0276 Hastelloy C22 – NiCr21Mo14W N06022 – 2.4602 NW 6022 Hastelloy B2 – – N10665 – 2.4617 – Hastelloy B3 Pipe Fittings Dimensional Normal Size Of Pipe (NPS) Outer Diameter (OD) ANSI B16.9 45 Degree Elbow ANSI B16.9 90 Degree Elbow ANSI B16.9 180 Degree Elbow (inches)   ANSI B16.9 Long Radius Elbow ANSI B16.9 LR Elbow ANSI B16.9 SR Elbow ANSI B16.9 Long Radius Elbow   (Inches/ inch.) (MM/ millimeter) Face To Center(Inche) Radius(Inche) Face To Center(Inche) Face To Center(Inche) Back to face(Inches) Center to Center(Inches) 1/2 0.0840 21.03 5/8   1 1/2 – 1 7/8 2 3/4 1.0050 26.07 7/16   1 1/8 – 1 11/16 2 1/4 1 1.0315 33.04 7/8   1 1/2 1 2 3/16 3 1 1/4 1.0660 42.02 1   1 7/8 1 1/4 2 3/4 3 3/4 1 1/2 1.0900 48.03 1 1/8 3 2 1/4 1 1/2 3 1/4 4 1/2 2 2.0375 60.03 1 3/8 4 3 2 4 3/16 6 2 1/2 2.0875 73.00 1 3/4 5 3 3/4 2 1/2 5 3/16 7 1/2 3 3.0500 88.09 2 6 4 1/2 3 6 1/4 9 3 1/2 4.0000 101.06

Hastelloy C276 Buttweld Fittings Read More »

Inconel 625 Fittings

Inconel 625 Fittings | Alloy 625 Buttweld Elbow

Nickel Alloy Buttweld Fittings /

Inconel 625 Fittings | Alloy 625 Buttweld Elbow Inconel 625 fittings , a high-performance nickel-chromium-molybdenum-niobium alloy, was developed precisely for these extreme demands. It’s a material trusted in industries where the environment eats ordinary steel for breakfast and even many stainless alloys don’t last.   But material alone isn’t enough. The way it’s fabricated—into precisely engineered buttweld fittings—matters just as much. Buttweld fittings offer robust, permanent, leak-resistant joints that can survive decades of thermal cycles, vibration, pressure pulses, and corrosive media without giving up.   Imagine an oil rig in the middle of the sea battling salt-laden winds, or a chemical plant pumping acids at high temperatures. These facilities can’t afford leaks, weak points, or corrosion-induced failures. They need seamless integration, long service life, and confidence that every connection is as strong as the pipe itself.   When you invest in Inconel 625 buttweld fittings, you’re not just buying a component—you’re investing in peace of mind. You’re telling your customers, regulators, and shareholders: We take safety and reliability seriously.   Inconel 625 is a nickel-chromium-molybdenum-niobium alloy (UNS N06625) with excellent resistance to: High-temperature oxidation Pitting and crevice corrosion Stress corrosion cracking Fatigue and creep It is known for exceptional strength without the need for precipitation-hardening treatments, thanks to solid solution strengthening with molybdenum and niobium. Table of Contents Inconel 625 Fittings Alloy 625 Buttweld Elbow UNS N06625 Tee Inconel 625  Fittings Specification Specifications ASTM B366 / ASME SB366, ASTM B366 UNS N06625, ASME SB366 UNS N06625 Alloy 625 Fittings size ASTM B366 UNS N06625 Seamless Fittings: 1/2″ – 10″UNS N06625 Grade 2 Butt Weld Fittings: 1/2″ – 48″ 2.4856 Inconel 625 Pipe Fittings Standards ASME B16.9, ASME B16.11, ASME B16.28, MSS-SP-43, BS4504 , BS4504, BS1560, BS10 Inconel 2.4856 Alloy 625 Fittings Available Thickness Schedule 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 Din 2.4856 Buttweld fitting Main Types Seamless / Welded / Fabricated ASME SB 366 Gr. 625 Threaded Fittings Thread NPT , BSPT, BSPP Nickel Alloy 625 Fittings Type DN15-DN1200 End Threaded, Welding, JIC Alloy 625 UNS N06625 Gr.1 Forged Fittings Pressure Rating 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS Connection Welding Inconel 625 Fitting Test Certificates EN 10204/3.1BRaw Materials Certificate100% Radiography Test ReportThird Party Inspection Report, etc Types of Inconel 625 Fittings Alloy 625 Buttweld Fittings ASTM B564 UNS N06625 Forged Fittings UNS N06625 Grade 2 Socket weld Fittings 2.4856 Inconel 625 Threaded Fittings Inconel 2.4856 Alloy 625 Tube Fittings Din 2.4856 Ferrule Fittings ASME SB 564 Gr. 625 Compression Fittings Nickel Alloy 625 Compression Tube Fittings Alloy 625 UNS N06625 Gr.1 Hydraulic Fittings Inconel 625 Flare Fittings Alloy 625 Flare Tube Fittings ASTM B564 UNS N06625 Compression Pipe Fittings UNS N06625 Grade 2 Pneumatic Pipe Fittings 2.4856 Inconel 625 Npt /Bsp / Bspp/ Bspt Tube Fittings Contact our Dealers and distributors in Australia, Poland, Malaysia, Canada, USA, Iran, Singapore, Italy, UAE, UK Uses & Application For Inconel 625 piping connection in Petroleum, Power, Chemical, Construction, Gas, Metallurgy, Shipbuilding etc Alloy 625 Schedule 10 fittings are an economical alternative for lower-pressure applications. ASTM B366 UNS N06625 Schedule 40 fittings have a thicker wall for higher-pressure applications. Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175   Value Added services: Inconel 2.4856 Alloy 625 45 degree Elbow Types of ASTM B564 UNS N06625 Tube Fittings Inconel 625 Tube to Union Alloy 625 Union Tee ASTM B564 UNS N06625 Reducing Union UNS N06625 Grade 2 Bulkhead Union 2.4856 Inconel 625 Union Elbow Inconel 2.4856 Alloy 625 Union Cross Din 2.4856 Tube To Male Fittings ASME SB 564 Gr. 625 Male Connector Nickel Alloy 625 Male Elbow NPT Alloy 625 UNS N06625 Gr.1 Male Bulkhead Connector Inconel 625 Male Elbow 45 Degree Alloy 625 Male Run Tee ASTM B564 UNS N06625 Male Branch Tee Inconel 625 Tube to Female Pipes Alloy 625 Female Connector NPT Imperial Series ASTM B564 UNS N06625 Female Connector NPT Metric Series UNS N06625 Grade 2 Female Connector BSP / BSPP 2.4856 Inconel 625 Female Bulkhead Connector Inconel 2.4856 Alloy 625 Female Elbow Din 2.4856 Female Run Tee ASME SB 564 Gr. 625 Female Branch Tee Inconel 625 Hydraulic Fittings Alloy 625 Bend Fittings ASTM B564 UNS N06625 Standard Hose Fittings UNS N06625 Grade 2 Banjo Fittings 2.4856 Inconel 625 Reusable Fittings Inconel 2.4856 Alloy 625 Industrial Hose Fitting Din 2.4856 Hydraulic Nipples ASME SB 564 Gr. 625 Metric Hydraulic Nipples    Inconel 625 Buttweld Fittings Types Inconel 625 90 Deg Long Radius Elbow Alloy 625 Eccentric Reducer Alloy 625 90 Deg Short Radius Elbow ASTM B366 UNS N06625 Stub End ASTM B366 UNS N06625 45 Deg Long Radius Elbow UNS N06625 Grade 2 End Cap UNS N06625 Grade 2 Buttweld Elbow 2.4856 Inconel 625 Pipe Cap 2.4856 Inconel 625 Elbow Inconel 2.4856 Alloy 625 Reducer Inconel 2.4856 Alloy 625 Seamless Butt Weld Fittings Din 2.4856 Long Radius Bend Din 2.4856 45 Deg Short Radius Elbow ASME SB 366 Gr. 625 Pipe Elbow ASME SB 366 Gr. 625 U Bend Nickel Alloy 625 5D Bend Nickel Alloy 625 180 Deg Long Radius Elbow Alloy 625 UNS N06625 Gr.1 Pipe Tee Alloy 625 UNS N06625 Gr.1 180 Deg Short Radius Elbow Inconel 625 Pipe Cross Inconel 625 Equal Cross Alloy 625 Welded Pipe Fittings Alloy 625 Stubends ASTM B366 UNS N06625 Seamless Pipe Fitting ASTM B366 UNS N06625 Equal Tee UNS N06625 Grade 2 Pipe Reducer UNS N06625 Grade 2 Tees 2.4856 Inconel 625 Pipe Nipple 2.4856 Inconel 625 Reducing Tee Inconel 2.4856 Alloy 625 Pipe End Cap Inconel 2.4856 Alloy 625 Eccentric Reducer Din 2.4856 End Pipe Cap Din 2.4856 Concentric Reducer ASME SB 366 Gr. 625 Pipe Bends ASME SB 366 Gr. 625 Cross Nickel Alloy 625 Lap Joint Nickel Alloy 625 Straight Cross Alloy 625 UNS N06625 Gr.1 Buttweld Fittings Alloy 625 UNS N06625 Gr.1 Reducing Cross Inconel 625 Piggable Bend Inconel 625 Concentric Reducer Alloy 625 Lateral Tee   Types of Inconel 2.4856 Alloy 625 Forged

Inconel 625 Fittings | Alloy 625 Buttweld Elbow Read More »

API 5L X65 Pipe

API 5L X65 Pipe Specification (PSL1, PSL2)

API 5L Pipes /

API 5L X65 Pipe Specification (PSL1, PSL2) API 5L X65 pipe has earned its place as a preferred choice for demanding pipeline projects. It’s not just another carbon steel pipe — it’s a workhorse material trusted by engineers, EPC contractors, and oil & gas majors worldwide.   Whether you’re building a cross-country natural gas pipeline, setting up an offshore drilling infrastructure, or constructing a petroleum transmission network in challenging terrains, API 5L Grade X65 line pipes deliver the mechanical toughness and reliability your project needs. They are engineered to operate under high internal pressures, withstand corrosive environments, and provide long-term service life even in the most demanding applications.   As the global energy sector grows more complex, the need for stronger and more efficient pipeline materials is greater than ever. That’s where X65 grade pipes stand out. Manufactured to API 5L and ISO 3183 standards, these pipes are available in both PSL1 and PSL2 categories, offering options that suit everything from general purpose fluid transport to critical oil & gas operations in sour service (H2S) environments.   What makes API 5L X65 so popular isn’t just its strength — it’s the balance between performance and economy. It offers a higher yield strength than X52 and X60, but without the cost burden of grades like X70 or X80. That’s why industries operating in cost-sensitive and performance-critical regions — such as India, the Middle East, Africa, and South America — consistently choose X65 for large-scale pipeline installations.   These pipes come in a wide range of diameters (from 1/2″ to 60″), wall thicknesses (SCH 10 to XXS), and types (Seamless, ERW, LSAW, DSAW), giving project managers and design engineers unmatched flexibility in choosing the right fit for their application. And with coatings like 3LPE, FBE, galvanized, or bare black, X65 pipes can be tailored for use in above-ground, buried, or submerged installations. X65 Material Equivalent ASTM API 5L Specification for line pipe Material Grade PSL1 L450 or x65 Material Grade PSL2 L450Q or X65QL450M or X65M API 5L X65 yield strength Grade Yield Strength Tensile Strength Yield to Tensile Elongation   min. (KSI) min. (KSI) Ratio (max) % API 5L X65 Pipe 65 77 0.93 18 As a supplier we are responsible for high quality in API 5L X65 Seamless Pipe Suppliers and API 5L X65 PSL2 Material Stock of Manufacturers Like ISMT, MSL, JSW, ArcelorMittal and NSSMC   API 5L GrB X65 PSL 1 Mechanical Properties Grade Yield Strength Mpa Tensile Strength Mpa Elongation B 245 415 c X65 450 535 c API 5L X65Q PSL 2 Mechanical Properties Grade Yield Strength Mpa Tensile Strength Mpa Raito Elongation   min max min max max min BN 245 450 415 655 0.93 f BQ X65Q 450 600 535 760 0.93 f API 5L X65 PSL2 Specification Specification API 5L X65, ASTM A1024 / A1024M, ISO 3183, API 5L X65m, API 5L X65mo psl2, API 5L X65M PSL2 Scope Covers Seamless, Welded, ERW pipes are suitable to convey water, gas and oil in both the oil and natural gas industries. Hot-Dipped Galvanizing May be ordered galvanized. supplying techniques API 5L X65 Welded Spiral submerged arc welded pipe (SSAW) Resistance welded pipe (ERW) Straight seam submerged arc welding pipe(LSAW) API 5L X65 Seamless Pipes Suppliers API 5L X65 ERW Pipe Suppliers API 5L X65 SAW Pipe Suppliers   API 5L X65 Pipe Suppliers Standard API 5L X65 (Specification for Line Pipe – ANSI/API specification 5L – 44th Edition, October 1, 2007) API 5L Grade X65q Pipe Applications Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes API 5L X65 Grade Pipe Testing and Inspection Reports EN 10204 3.1, Mill TC EN 10204 3.1, PMI Test Reports, Visual Inspection Reports, Destructive Test Report, Non Destructive Test Reports, NABL Approved Lab, Chemical and Mechanical Reports, India Boiler Regulations (IBR) Test Certificate, Third Party Inspection Reports API 5L X65 Grade Pipe Sizes Nominal Pipe Size 1/2″ to 48 ” O.D.Wall Thickness – Schedule 10 through 160, STD, XS, XXS. API 5L X65 Pipe Finishes Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap.End Finishes:Beveled, Square Cut, Threaded & Coupled. API 5L X65 Pipe Pipe End Plain, Bevel, Screwed, Threaded API 5L X65m Pipe Product Specification Level (PSL) API 5L X65 PSL 2 Pipe SuppliersAPI 5L X65 PSL 1 Pipe Suppliers Application & uses of API 5L X65 Dsaw Pipe Suitable for Conveying gas, water, oil, and other liquefied media. API 5L X65 Pipe Wall Thickness SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All API 5L X65 Pipe Schedule API 5L X65 Pipe Suppliers Value added service Tar Epoxy ARO Machining Bending Fusion Bond Epoxy For DWT, DNV requires production of a transition curve, so there will be a range of test temperatures that will straddle the minimum design temperature. Heat Treatment 3LPE Galvanizing Sand Blasting Draw & Expansion as per required Size & Length etc. API 5l x65 charpy: Charpy Impact test temperature for API 5L X65M PSL2 material, Design code is DNV-OS-F101: Refer Table 7-5 on page 114 or if supplementary F requirements are being applied, Table 7-23 on page 135 Annealed Packing of api 5l x65 pipe suppliers uk API 5L X65 GR. B Pipe Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests Caracteristicas Tuberia Api 5L X65 BS EN 10208-2:2009 API 5L X65 pipelines for combustible fluids. Suitable to use in maximum operating pressure over 16 bar. API 5L X65 Pipe Specialized in API 5L X65 saw API 5L X65 smls API 5L X65 sour service API 5L X65 smys API 5L X65 Seamless Pipe Suppliers API 5L X65 Pipes Suppliers Type Seamless / ERW / Welded / Fabricated / CDW API 5L X65 Line Pipe Length Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths Specifications of ISO 3183 grade L450 ERW Pipe Suppliers, tuberia api 5l x65 psl2 and X65 PSL1 smls Line pipe

API 5L X65 Pipe Specification (PSL1, PSL2) Read More »

API 5L X70 pipes

API 5L X70 Pipe mechanical properties

API 5L Pipes /

api 5l x70 pipe API 5L X70 pipe isn’t just another steel pipe — it’s a high-yield strength pipeline material that represents a critical intersection of engineering innovation, metallurgical advancement, and real-world performance in challenging environments. Developed as part of the American Petroleum Institute’s API 5L specification, this pipe is designed for high-pressure transmission systems that transport vital resources like crude oil, natural gas, petroleum products, slurry, water, and even hydrogen gas across great distances — including terrains that are corrosive, abrasive, and geographically harsh.   The designation “X70” refers to its minimum yield strength of 70,000 psi (or 485 MPa), which makes it significantly stronger than lower-grade line pipes such as X42, X52, or X60. This strength allows operators to use thinner pipe walls to achieve the same performance, ultimately reducing material weight and transport cost — a critical factor in mega infrastructure projects. But beyond its strength, API 5L X70 is prized for its: Durability in extreme temperatures — including arctic and desert conditions Resistance to sour gas environments (H2S) when used with PSL2 specifications Excellent weldability, making field fabrication quicker and more reliable Availability in a wide range of diameters, thicknesses, and forms (seamless, ERW, LSAW, DSAW) Customizable coatings and finishes to suit offshore, subsea, and underground conditions   API 5L X70 is a true workhorse in pipeline engineering, supporting the global oil & gas network, water distribution systems, and large-scale utility infrastructure. It is commonly specified in both onshore cross-country transmission pipelines and offshore pipeline construction, where environmental demands are higher and maintenance is costly. API 5L X70 PIPE Table of Contents What is API 5L X70 Pipe? When it comes to designing pipelines for the transportation of oil, natural gas, petroleum products, water, or even slurry across long distances — often through harsh environments — selecting the right type of pipe is absolutely critical. That’s where API 5L Grade X70 stands out as a preferred choice in the global pipeline industry.   API 5L is a well-established standard developed by the American Petroleum Institute that specifies requirements for manufacturing seamless and welded steel line pipes. These pipes are intended specifically for pipeline transportation systems in the oil, gas, and petrochemical sectors. API 5L is widely recognized and used in projects all over the world — from North America and the Middle East to Asia, Africa, and beyond click here for more details. seamless pipes line pipes Api 5l X70 Pipe properties API 5L X70 PSL 1 Chemical Requirements Grade Composition, % C max Mn max P S max V max Nb max Ti max min max B 0.28 1.2 – 0.03 0.03 c.d c,d d X70 0.28 1.4 – 0.03 0.03 f f f                          API 5L X70Q PSL 2 Chemical Requirements Grade Composition, % C Si Mn P S V Nb Ti Other   X70Q 0.18 0.45 1.8 0.025 0.015 g g g h,l   API 5L X70 Welded Pipe Price List for India, Ready Stock of API 5L X70 Steel Pipe in Large Diameter   Grade Chemical Composition   C Si Mn P S V Nb Ti API 5L X70 0.17 0.45 1.75 0.020 0.010 0.10 0.05 0.06 API 5L X70 Pipe Specification Hot-Dipped Galvanizing May be ordered galvanized. supplying techniques API 5l X70 Welded Pipe Suppliers Spiral submerged arc welded pipe (SSAW) Straight seam submerged arc welding pipe(LSAW) Resistance welded pipe (ERW) Api 5l X70 Seamless Pipe Suppliers Specification API 5L X70, ASTM A1024 / A1024M, ISO 3183 Scope Covered Seamless, Welded, ERW pipes are suitable to convey water, gas and oil in both the oil and natural gas industries.   API 5L X70 Pipes Type Seamless / ERW / Welded / Fabricated / CDW / SAW Spiral Pipe Packing API 5L X70 GR. B Pipe Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests Api 5l X70 Erw Pipe Standard API 5L X70 (Specification for Line Pipe – ANSI/API specification 5L – 44th Edition, October 1, 2007), ASME/ANSI B36.10 Application & uses Suitable for Conveying gas, water, oil, and other liquefied media. Product Specification Level (PSL) API 5L X70 PSL 2API 5L X70 PSL 1 API 5l X70 Seamless Pipes Finishes Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap. End Finishes :Beveled, Square Cut, Threaded & Coupled. Value added service Sand Blasting Galvanizing Bending Heat Treatment ARO Draw & Expansion as per required Size & Length etc. Fusion Bond Epoxy Annealed Machining 3LPE Tar Epoxy Tubo API 5L Gr X70 Pipe End Plain, Bevel End, Screwed, Threaded Sizes Nominal Pipe Size 1/2″ to 48 ” O.D.Wall Thickness – Schedule 10 through 160, STD, XS, XXS. Iso 3183 L485 Pipe Thickness SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules API 5L X70 Line Pipe Length Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths Applications Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes BS EN 10208-2:2009 API 5L X70 pipelines for combustible fluids. Suitable to use in maximum operating pressure over 16 bar. API 5L X70 Material Testing and Inspection Reports EN 10204 3.1, Mill TC EN 10204 3.1, PMI Test Reports, Visual Inspection Reports, Destructive Test Report, Non Destructive Test Reports, NABL Approved Lab, Chemical and Mechanical Reports, India Boiler Regulations (IBR) Test Certificate, Third Party Inspection Reports API 5L X70 Pipe Psl2 Material Equivalent ASTM API 5L Specification for line pipe Material Grade PSL1 L485 or x70 Material Grade PSL2 L485Q or X70QL485M or X70M L485Q Steel Pipe supplier, ISO 3183 L485 material for sale at best price in India API 5L  X70 Pipe yield strength Grade Yield Strength Tensile Strength Yield to Tensile Elongation   min. (KSI) min. (KSI) Ratio (max) % API 5L X70 70 82 0.93 17 API 5L X70 Pipe PSL 1/2 Mechanical Properties Grade Yield Strength Mpa Tensile Strength Mpa Raito Elongation

API 5L X70 Pipe mechanical properties Read More »

API 5L pipe

API 5L pipe Supplier and line dimensions

API 5L Pipes /

API 5L pipe Supplier and line dimensions API 5L Pipes stand out as one of the most trusted materials in the industry. Designed and certified under the globally recognized American Petroleum Institute (API) specification, API 5L line pipes are the backbone of critical pipeline infrastructure across the world. Whether you’re working on a small utility project or a large-scale oil & gas transmission line, API 5L steel pipes offer consistent quality, strength, and performance.   API 5L is a specification that covers seamless and welded carbon steel line pipes intended for use in pipeline transportation systems. These pipes are suitable for conveying gas, water, and oil across both aboveground and underground installations.  API 5L includes two major specification levels: PSL1 (Product Specification Level 1) – Standard quality, basic mechanical and chemical properties.   PSL2 (Product Specification Level 2) – Enhanced performance, tighter tolerances, better mechanical properties, and additional testing for critical service.   API 5L pipes come in various steel grades such as X42, X46, X52, X56, X60, X65, X70, and X80 — each indicating its minimum yield strength in 1000s of PSI. Table of Contents Key Features of API 5L Line Pipes  Manufactured to international standards (API 5L / ISO 3183)  Available in seamless, ERW, LSAW, and DSAW forms Suitable for sour service (NACE MR0175 / H2S environments)  Available in black, bare, coated, and galvanized finishes  Cut-to-length and beveled-end options available  Wide range of thicknesses: SCH 10 to SCH XXS and beyond  Mill Test Certificates (MTC) & third-party inspection reports provided API 5L Pipe specification Kinds of Steel Permitted For For Pipe Material Open-hearthElectric-furnaceBasic-oxygen Hot-Dipped Galvanizing May be ordered galvanized. Supplying techniques Welded Pipe Straight seam submerged arc welding pipe(LSAW) Resistance welded pipe (ERW) Spiral submerged arc welded pipe (SSAW) Seamless Pipe ERW Pipe SAW Pipe Hot rolled seamless pipe upto 20 inch (508 mm)Seamless pipe (hot expanding processes) : upto 40 inch 1016 mm. Specification ASTM A1024 / A1024M, API 5L, ISO 3183 Scope Covers WELDED and SEAMLESS pipe suitable for use in conveying gas, water, and oil in both the oil and natural gas industries. API 5L Welded Pipe Standard API 5L (Specification for Line Pipe – ANSI/API specification 5L – 44th Edition, October 1, 2007) Sizes Nominal Pipe Size 1/2″ to 48 ” O.D.Wall Thickness – Schedule 10 through 160, STD, XS, XXS. Value added service for Line Pipe Suppliers In India Sand Blasting Fusion Bond Epoxy Tar Epoxy ARO Annealed Draw & Expansion as per required Size & Length 3LPE Galvanizing Heat Treatment Bending Machining etc. API 5L Pipes Type Seamless / ERW / Welded / Fabricated / CDW Product Specification Level (PSL) API 5L PSL 2API 5L PSL 1 API 5L Dsaw Pipe Applications Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes API 5L Seamless Pipe End Plain, Bevel, Screwed, Threaded Thickness SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules API Line Pipe Length Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths Testing and Inspection Reports EN 10204 3.1, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, Destructive Test Report, Non Destructive Test Reports, Mill TC EN 10204 3.1, NABL Approved Lab, Chemical and Mechanical Reports, India Boiler Regulations (IBR) Test Certificate API 5L PSL1 Pipe Finishes Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap. End Finishes: Beveled, Square Cut, Threaded & Coupled. API 5L Schedule 40 Pipe Packing API 5L GR. B Pipe Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests API 5L Seamless and Welded Pipe Application & uses Suitable for sour services and in H2S environment Large diameter API 5L Pipe for high pressure gas transportation Suitable for Conveying gas, water, oil, and other liquefied media. Thick wall API 5L Pipe for submarine pipeline HS Code 730451 Tubes, Pipes and Hollow Profiles, of Other Alloy Steel, Cold-drawn or cold-rolled (cold reduced) 730490 Other Tubes, Pipes and Hollow Profiles, Seamless, of Iron or Steel 730420 Casing, tubing and drill pipe, of a kind used in drilling for oil or gas: Casing: 730431 Tubes, Pipes and Hollow Profiles, of Iron or Non-alloy Steel, Cold-drawn or cold-rolled (cold-reduced) 730439 Other Tubes, Pipes and Hollow Profiles, of Iron or Non-alloy Steel 730449 Other Tubes, Pipes and Hollow Profiles, of Stainless Steel, Seamless 730459 Other Tubes, Pipes and Hollow Profiles, of Other Alloy Steel, 730410 Line pipe of a kind used for oil or gas pipelines: Of iron or nonalloy steel: 730441 Tubes, Pipes and Hollow Profiles, of stainless steel , Cold-drawn or cold-rolled (cold reduced) Test Methods Flattening test Hydrostatic test CVN impact test for PSL2 pipe (including pipe body tests, pipe weld and HAZ tests) DWT test for PSL2 welded pipe Bend test Guided-bend test BS EN 10208-2:2009 Steel pipes for pipelines for combustible fluids. Technical delivery conditions. Pipes of requirement class B. Suitable to use in maximum operating pressure over 16 bar. Grades API 5L Pipe Suppliers in India Grade L210 / A 210 MPa (30.5 ksi) YS335 MPa (48.6 ksi) UTS Grade L245 / B 245 MPa (35.5 ksi) YS415 MPa (60.2 ksi) UTS Grade L175 / A25 175 MPa (25.4 ksi) YS310 MPa (45.0 ksi) UTS Grade L290 / X42 290 MPa (42.1 ksi) YS415 MPa (60.2 ksi) UTS Grade L320 / X46 320 MPa (46.4 ksi) YS435 MPa (63.1 ksi) UTS Grade L360 / X52 360 MPa (52.2 ksi) YS460 MPa (66.7 ksi) UTS Grade L390 / X56 390 MPa (56.6 ksi) YS490 MPa (71.1 ksi) UTS Grade L415 / X60 415 MPa (60.2 ksi) YS520 MPa (75.4 ksi) UTS Grade L450 / X65 450 MPa (65.3 ksi) YS535 MPa (77.6 ksi) UTS Grade L485 / X70 485 MPa (70.3 ksi) YS570 MPa (82.7 ksi) UTS Grade L555 / X80   Grade X100 and X120   API 5L Seamless and Welded Pipe Delivery Condition PSL Delivery condition Pipe grade/steel gradea,b PSL1 As-rolled, normalizing rolled, normalized or normalizing formed L176 or A25 L175P or A25P L210 or A As-rolled, normalizing rolled, thermomechanical rofled, thermoinechanical formed,  normalizing formed, normalized , normalized and tempered; or, If agreed,  quenched and tempered for SMLS pipe only L245 or

API 5L pipe Supplier and line dimensions Read More »

ASTM A671 STEEL PIPE

A671 STEEL PIPE

Stainless Steel Pipes /

ASTM A671 STEEL PIPE ASTM A671 Steel Pipes step in as a dependable solution engineered to perform in challenging environments. At Prosaic Steel and Alloys, we understand that quality, consistency, and delivery timelines can make or break a project. That’s why we specialize in the manufacturing, fabrication, import, and supply of A671 CC60, CC65, and CC70 Electric Fusion Welded (EFW) Pipes—serving both domestic and global clients with the same precision and professionalism. With years of experience in handling carbon steel piping solutions, we have built a reputation as one of India’s largest stockholders and premier suppliers of ASTM A671 Pipes. Our inventory includes a comprehensive range of A671 LSAW (Longitudinal Submerged Arc Welded) Pipes, available in custom sizes, wall thicknesses, and pressure ratings—ensuring suitability for everything from low-temperature fluid transportation to high-pressure pipelines in thermal plants and chemical facilities.   What makes ASTM A671 Pipes particularly useful is their origin: these pipes are manufactured using pressure vessel quality plates—the same high-grade steel plates used in making industrial boilers and vessels. The electric fusion welding process adds strength, while the optional heat treatment helps achieve specific mechanical properties. These pipes are not only durable and dimensionally accurate but also capable of withstanding stress in extreme conditions, whether it’s sub-zero temperatures or aggressive chemical exposure.   At Prosaic Steel and Alloys, we don’t just sell steel—we provide performance-driven piping solutions tailored to your technical and operational needs. Whether you need a small batch for replacement parts or bulk procurement for large infrastructure projects, our team ensures quick turnaround, global shipping, and compliance with ASTM and ASME standards.   ASTM A671 Carbon Steel Pipes step in as a dependable solution engineered to perform in challenging environments. At Prosaic Steel and Alloys, we understand that quality, consistency, and delivery timelines can make or break a project. That’s why we specialize in the manufacturing, fabrication, import, and supply of A671 CC60, CC65, and CC70 Electric Fusion Welded (EFW) Pipes—serving both domestic and global clients with the same precision and professionalism. With years of experience in handling carbon steel piping solutions, we have built a reputation as one of India’s largest stockholders and premier suppliers of ASTM A671 Pipes. Our inventory includes a comprehensive range of A671 LSAW (Longitudinal Submerged Arc Welded) Pipes, available in custom sizes, wall thicknesses, and pressure ratings—ensuring suitability for everything from low-temperature fluid transportation to high-pressure pipelines in thermal plants and chemical facilities.   What makes ASTM A671 Pipes particularly useful is their origin: these pipes are manufactured using pressure vessel quality plates—the same high-grade steel plates used in making industrial boilers and vessels. The electric fusion welding process adds strength, while the optional heat treatment helps achieve specific mechanical properties. These pipes are not only durable and dimensionally accurate but also capable of withstanding stress in extreme conditions, whether it’s sub-zero temperatures or aggressive chemical exposure.   ASTM A671 Pipe Specification ASTM A671 Pipe Specification ASTM A671 /ASME SA671 Grades ASTM A671 Grade CC60 ASTM A671 Grade CC65 ASTM A671 Grade CC70 Type EFW (ELECTRIC FUSION WELDED PIPES) Class Designation CLASS 10, 11, 12, 13, 20, 21, 22, 23, 30, 31, 32, 33, 40, 41, 42 Outer Diameter Size 16″ NB To 100″ NB (Nominal Bore Size) Wall Thickness Schedule 20 To Schedule XXS (Heavier On Request) Up to 250 mm Thickness ASTM A671 EFW Pipes Length 5 To 7 Meters, 09 To 13 Meters, Single Random Length, Double Random Length And Customize Size. Ends Plain Ends / Beveled Ends / Coupling Delivery Conditions As Rolled, Normalizing Rolled, Thermomechanical Rolled / Formed, Normalizing Formed,Normalized and Tempered / Quenched and Tempered – BR / N / Q /T Coating Epoxy Coating / Colour Paint Coating / 3LPE Coating. Other Testing NACE MR0175, NACE TM0177, NACE TM0284, CHARPY V-NOTCH TEST, RADIOGRAPHIC EXAMINATION,XRAY, ULTRASONIC EXAMINATION, LIQUID PENETRANT, MAGNETIC PARTICLE, HIC TEST, SSC TEST, SWC, H2 SERVICE, IBR, PWHT etc. Dimension All Pipes Is suppliers and Inspected / Tested to the Relevant standards including ASTM, ASME, API. Value Added Services Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Galavanizing / Heat Treatment Packaging Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector Shipment & Transportation By Road – Truck / Train, By Sea – Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) /20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container /Open Top Container, By Air – Freighter Civil Passenger and Cargo Planes Material Test Certificate suppliers Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. /Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC  ASTM A671 Pipe Equivalent ASTM A671 EFW Pipes Types Out diameter Wall thickness Length ASTM A671 EFW Pipes (Custom Sizes) 1/2″ NB – 60″ NB SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 Custom ASTM A671 Welded Pipes (in Stock + Custom Sizes) 1/2″ NB – 24″ NB As per requirement Custom ASTM A671 ERW Pipe (Custom Sizes) 1/2″ NB – 24″ NB As per requirement Custom ASTM A671 SAW Pipe 16″ NB – 100″ NB As per requirement Custom ASTM A671 Pipe / Tube Size Chart ASTM A671 EFW Pipes NB Sizes Sch 5 Sch 10 Sch 40 Sch 80 Sch 160 ASTM A671 1/2           ASTM A671 3/4           ASTM A671 1           ASTM A671 1.25           ASTM A671 1.5           ASTM A671 2           ASTM A671 2.5           ASTM A671 3           ASTM A671 3.5           ASTM A671 4           ASTM A671 5           ASTM A671 6           ASTM A671 8

A671 STEEL PIPE Read More »

ASTM A691

ASTM A691 Alloy Steel EFW Pipes

ASTM Alloy Steel EFW Pipes /

ASTM A691 Alloy Steel EFW Pipes ASTM A691 is a highly specialized and widely adopted standard developed by the American Society for Testing and Materials (ASTM) for electric-fusion-welded (EFW) steel pipes used in critical high-temperature and high-pressure service environments. These pipes are manufactured using pressure vessel-quality carbon or alloy steel plates, and the welding is carried out using added filler metal to ensure exceptional strength, integrity, and durability at elevated service conditions. The need for ASTM A691-grade pipes arises in sectors where both mechanical stress and thermal exposure are continuous and extreme — such as in refineries, thermal and nuclear power plants, oil and gas transmission systems, chemical processing units, and offshore rigs. These environments demand materials that not only meet structural expectations but also maintain performance over long service lifespans under harsh conditions. ASTM A691 meets these needs by offering a wide range of chromium-molybdenum-based alloy compositions that provide superior resistance to oxidation, corrosion, creep, and thermal fatigue. Unlike seamless or standard welded pipes, ASTM A691 pipes are fabricated using a method that combines heavy-duty steel plates with electric-fusion welding techniques. This process allows the production of large-diameter pipes (typically 16 inches and above), which are difficult to achieve through conventional pipe manufacturing processes. The use of filler metal during welding helps reinforce the joint, making it suitable for the transportation of high-pressure fluids and gases. Another distinguishing feature of ASTM A691 pipes is their classification system, which defines not only the alloy composition (grade) but also the manufacturing and inspection procedures (class). These classes determine whether the pipe is heat-treated, whether radiographic testing of the weld is performed, and whether a hydrostatic pressure test is conducted. The standard allows for various combinations of normalization, tempering, quenching, and post-weld heat treatments to achieve desired mechanical properties and code compliance, especially for use in environments governed by ASME Boiler and Pressure Vessel Codes. Over the years, ASTM A691 has become a go-to specification for engineers and project managers looking to balance reliability, performance, and cost-effectiveness in high-stakes industrial applications. With its robust mechanical properties, wide grade range, and flexible manufacturing options, ASTM A691 stands as a critical component in modern infrastructure for energy, process, and utility systems. A691 Material Specification Grade Alloy Steel ASTM A691 Cl22, A691 GRADE 1 CR, GRADE 1/2 CR, GRADE 1 1/4 CR, GRADE 2 1/4 CR,GRADE 3 CR, GRADE 5 CR, GRADE 9 CR, GRADE 91, CM 65, CM 70, CM 75 Size 1/2” NB to 36” NB Thickness 3-12mm Schedules SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS Class Designation Class 10, 11, 12, 13, 20, 21, 22, 23, 30, 31, 32, 33, 34, 40, 41, 42, 43, 50,51, 52, 53, 60, 61, 62, 63, 70, 71, 72, 73 ASTM A691 Grades ASTM A691 Gr 11, ASTM A691 Gr.91, ASTM A691 9cr, ASTM A691 5cr, ASTM A691 1 1/4cr Cl22, ASTM A691m,ASTM A691 Gr.5cr Cl22, ASTM A691 Cm70, ASTM A691 Class 22, ASTM A691 Class 42, ASTM A691-91, ASTM A691 Grade 2.1/4cr, ASTM A691 11/4cr Cl22 Origin European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) Tolerance Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm Craft Cold rolled and Cold drawn Type Seamless / ERW / Welded / Fabricated / LSAW Pipes available in Form of Round, Square, Rectangular, Hydraulic Etc. Length StandardDouble &In Cut length also. End Plain End, Beveled End, Treaded Specialized in Large Diameter ASTM A691 Pipe Additional Testing NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. Application Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service ASTM A691 Pipe chemical composition Chemical Composition of A691 1-1/4CR, 2-1/4CR, 5CR, 9CR, 91 Alloy STEEL EFW PIPEs   1CR 1-1/4CR 2-1/4 CR 5 CR 9 CR 91 C 0.05-0.17 0.05-0.17 0.05-0.15 0.15 0.15 0.08-0.12 Mn 0.40-0.65 0.40-0.65 0.30-0.60 0.30-0.60 0.30-0.60 0.30-0.60 P 0.025 0.025 0.025 0.025 0.025 0.020 S 0.025 0.025 0.025 0.025 0.025 0.010 Si 0.15-0.40 0.50-0.80 0.50 0.50 1.00 0.20-0.50 Cr 0.80-1.15 1.00-1.50 2.00-2.50 4.00-6.00 8.00-10.00 8.00-9.50 Mo 0.45-0.60 0.45-0.65 0.90-1.10 0.45-0.65 0.90-1.10 0.85-1.05 V – – – – 0.04 0.18-0.25 *Grade 91 also includes restrictions on Nickel 0.40 max, Columbium 0.06-0.10, Nitrogen 0.030-0.070, Aluminium 0.02 max, titanium 0.01 max, Zirconium 0.01 max. ASTM A691 Pipe equivalent Pipe Grade Type of Steel ASTM Specification HB, max Number Grade CM-65 carbon-molybdenum steel A204/A204M A 201 CM-70 carbon-molybdenum steel A204/A204M B 201 CM-75 carbon-molybdenum steel A204/A204M C 201 CMSH-70 carbon-manganese-silicon steel, normalized A537/A537M 1   CMS-75 carbon-manganese-silicon steel A299/A299M — — CMSH-80 carbon-manganese-silicon steel, quenched and tempered A537/A537M 2   1/2 CR 1/2 % chromium, 1/2 % molybdenum steel A387/A387M 2 201 1 CR 1 % chromium, 1/2 % molybdenum steel A387/A387M 12 201 1 1/4 CR 1 1/4 % chromium, 1/2 % molybdenum steel A387/A387M 11 201 2 1/4 CR 2 1/4 % chromium, 1 % molybdenum steel A387/A387M 22 201 3 CR 3 % chromium, 1 % molybdenum steel A387/A387M 21 201 5 CR 5 % chromium, 1/2 % molybdenum steel A387/A387M 5 225 9 CR 9 % chromium, 1 % molybdenum steel A387/A387M 9 241 91 9 % chromium, 1 % molybdenum, vanadium, columbium A387/A387M 91 241 A Class I is Other Than Killed with a specified minimum tensile strength of 450 MPa or lower. Class II is Other Than Killed with a specified minimum tensile strength of 450 to 520 MPa incl. Class III is Killed with a specified minimum tensile strength of 450 MPa or lower. Class IV is Killed with a specified minimum tensile strength of 450 to 520 MPa incl. Class V is Killed with a specified minimum tensile strength of over 520 MPa to but not including 655 MPa. Class VI is Killed with a specified minimum tensile strength of 655 MPa or over. B Full size (10 by 10 mm) specimens. C Testing temperature as specified in the purchase order, but no higher than 0°C ASTM A691 Pipe mechanical properties A691 1-1/4CR, 2-1/4CR, 5CR, 9CR, 91 Alloy Steel EFW LSAW Pipes Class

ASTM A691 Alloy Steel EFW Pipes Read More »
